DVD port connector pinout's

Post by andre104623 » Sat Jun 13, 2015 4:46 pm

I removed a male DVD port connector from a DVD board. I have a few ideas for what I want to do with it but I need the pinout's before I do anything yet.
Red arrow points to the memory card slot
(1.77 MiB) Not downloaded yet
Xesxen
Posts: 28
Joined: Mon Jul 21, 2014 4:24 pm
Location: The Netherlands

Re: DVD port connector pinout's

Post by Xesxen » Sat Jun 13, 2015 7:54 pm

andre104623
Posts: 643
Joined: Wed May 07, 2014 2:24 pm

Re: DVD port connector pinout's

Post by andre104623 » Sun Jun 14, 2015 6:20 am

Thank you but were does pin 1 start and pin 32 end?
User avatar
Streetwalker
Posts: 1739
Joined: Mon Dec 30, 2013 7:50 am
Location: Israel

Re: DVD port connector pinout's

Post by Streetwalker » Sun Jun 14, 2015 6:30 am


As written on the drive board. Also I think the connector is symmetric.
Edit : woops I accidentally mirrored it. Fixed.

By the way, isn't there a way to set the image width in bbcode ? It's kind of annoying.
andre104623
Posts: 643
Joined: Wed May 07, 2014 2:24 pm

Re: DVD port connector pinout's

Post by andre104623 » Sun Jun 14, 2015 6:43 pm

Thank you very much. Yeah I forgot to look at the drive board sorry bout that
User avatar
Streetwalker
Posts: 1739
Joined: Mon Dec 30, 2013 7:50 am
Location: Israel

Re: DVD port connector pinout's

Post by Streetwalker » Sun Jun 14, 2015 6:57 pm

You welcome. Out of curiosity what do you plan to do with it ?
andre104623
Posts: 643
Joined: Wed May 07, 2014 2:24 pm

Re: DVD port connector pinout's

Post by andre104623 » Sun Jun 14, 2015 10:18 pm

Streetwalker wrote:You welcome. Out of curiosity what do you plan to do with it ?
I'm not sure yet but I was going to try have a WASP and DVD together without a megadrive v4. But really it's all up in my head still and I won't get to it till the fall or later. I have a lot of other things on my todo list
Sugurain
Posts: 35
Joined: Wed Dec 31, 2014 1:21 am

Re: DVD port connector pinout's

Post by Sugurain » Tue Jun 23, 2015 12:32 am

So, it IS possible to have Wasp and DVD togheter without a megadrive v4....
I's like to try that, as I've been doing a similar mod for my Dreamcast, the difference being that I'm installing a HDD on the DC.

Is there any guide to do this mod on the GC without the Megadrive V4?
andre104623
Posts: 643
Joined: Wed May 07, 2014 2:24 pm

Re: DVD port connector pinout's

Post by andre104623 » Tue Jun 23, 2015 3:05 pm

Sugurain wrote:So, it IS possible to have Wasp and DVD togheter without a megadrive v4....
I's like to try that, as I've been doing a similar mod for my Dreamcast, the difference being that I'm installing a HDD on the DC.

Is there any guide to do this mod on the GC without the Megadrive V4?
Oh yeah its possible. People have done it before like way before the megadrive v4 BUT I don't like messes of wires ( Known as wireporn ) so I really need to give this project some thought. Maybe need to design my own PCB to house the connector which if I do it will be the first time I design a PCB.
User avatar
Streetwalker
Posts: 1739
Joined: Mon Dec 30, 2013 7:50 am
Location: Israel

Re: DVD port connector pinout's

Post by Streetwalker » Tue Jun 23, 2015 5:25 pm

Thankfully it's not really hard. I designed a simple pcb for the first time in about an afternoon. If you're going to connect to a GC board you'll need to create your own footprints though (I was lucky enough to use only components that were already available in eagle's database).
Sugurain
Posts: 35
Joined: Wed Dec 31, 2014 1:21 am

Re: DVD port connector pinout's

Post by Sugurain » Tue Jun 23, 2015 6:58 pm

Oh, I see.
I didn't know people had done it before. I'm really new to the Cube scene, and 100 dollars for an simple adapter is just too much for me...
(that's like 600 bucks here in my country, belive it or not)

I too, don't like the "wire porn" but oh well... not much else I can do. hahaha

I'd like something like a diagram, where each pin should go, and if it was not that impossible, I'd surely give it a try hahaha.
Not sure if my DOL-002 would be compatible with this though.
Gonna ask Megalomaniac once the board I sent him arrives. =)
